Details
Features
Laser Features:
3 x 360° green laser planes for full-room layout coverage
Complete horizontal and vertical alignment without repositioning
GREENBEAM technology (510–530 nm) for superior visibility
Receiver-assisted working range up to 330 ft
Reliable indoor operation without a receiver in normal conditions
Self-leveling range ±4°
Accuracy ±1/8 in @ 30 ft
IP65 rated – water and dustproof for demanding projects
CAS 12V Li-Ion 2.0 Ah battery platform
Approx. 15-hour runtime
Receiver Features:
Compatible with pulse-modulated green and red laser lines
Illuminated digital display on both sides
Acoustic and visual guidance
Integrated magnet system on upper housing
Waterproof and dustproof – IP66 rated
Size
Technical Data:
Receiver Sensitivity: ±1/32 in (Fine), ±1/8 in (Coarse)
Receiver Protection Rating: IP66
Receiver Line Height: 3-1/2 in (90 mm)
Receiver Runtime: Up to 45 hours
Self-Levelling Range: +/- 4°
Levelling accuracy: +/- 1/8 in @ 30 ft
Laser Wavelength: 510 - 530 nm
Measuring Range of Visible Line: 330' with Receiver
Operating Life: Approximate 15 Hours
Laser Class: 2
Power Supply: CAS 12V Li-Ion 2.0Ah
Protection Class: IP65
